X4 Active Frequency Multiplier with Uni-Guide™

SFA-243423413-28SF-E1 is an active X4 frequency multiplier. The multiplier has an input frequency of 6 to 10.5 GHz with a typical input power of +5 dBm and an output frequency of 24 to 42 GHz with a typical output power of +13 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The DC power requirement for the multiplier is +8 VDC/300 mA. The input port of this model is a female SMA connector and the output port is a WR-28 Uni-Guide™ waveguide with a UG-599/U flange. It is an in-line angle configuration. Other port configurations, such as right angle, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
