2.92 mm Coaxial Bandstop Filter

24 to 24.25 GHz Rejection Frequency, 40 dB Rejection
SKU:SCF-24324340-KFKF-N3
Availability:6 to 8 Weeks ARO
SCF-24324340-KFKF-N3 is a coaxial band stop filter with passband frequencies from DC to 23.5 GHz and 25 to 40 GHz and a rejection frequency from 24.0 to 24.25 GHz. The filter provides a typical insertion loss of 3.0 dB across its passband and a minimum rejection of 40 dB at this rejection band.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 2$3,650.00
3 - 4$3,467.50
5 - 9$3,294.13

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Passband Frequency, High Side25 GHz
Maximum Passband Frequency, High Side40 GHz
Minimum Rejection Frequency, Low SideDC
Maximum Rejection Frequency, Low Side23.5 GHz
Minimum Rejection Frequency24 GHz
Maximum Rejection Frequency24.25 GHz
Rejection40 dB
Return Loss9 dB
RF Ports2.92 mm Female
