K-Band Volume Production Oscillator, Limited Run

24.125 GHz, ±1.00 GHz Tuning Bandwidth, +18 dBm Output Power, WR-42 Waveguide
SKU:SOL-24318-42-G1
Availability:1 to 2 Weeks ARO
This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should contact us for an alternative model. Read more about Limited Run Products here.

SOL-24318-42-G1 is a volume-production ready, K Band Gunn oscillator that utilizes a high performance GaAs Gunn diode and high Q cavity to achieve excellent phase noise and power stability. The oscillator is designed for fixed frequency applications, however, the frequency can be adjusted by ±1.0 GHz using the self-locking set screw provided.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 24 $490.00
25 - 49 $441.00
50 - 99 $396.90

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Center Frequency24.125 GHz
Output Power+18 dBm
Mechanical Tuning Range±1000 MHz
Varactor Tuning Range-
Phase Noise-98 dBc/Hz @ 100 KHz offset
Bias+6.0 VDC/650 mA
Varactor Tuning Voltage Range-
RF PortWR-42 Waveguide
