Ka-Band Orthomode Transducer

SAT-343-28028-S1 is a broadband orthomode transducer (OMT) that operates from 23 to 44 GHz. This model is specifically designed to cover 5G FR2 bands n257 thru n261. The OMT separates a circular or elliptical polarized waveform into two linear, orthogonal waveforms or combines two linear polarized waveforms into one circular or elliptical polarized waveform or vice versa. The OMT supports vertical and horizontal polarized waveguide forms with high port isolation and low insertion loss. The common antenna port is a 0.280” square waveguide, while the vertical and horizontal ports are standard WR-28 waveguides with UG599/U flanges. Additional customization options, such as converting the horizontal and vertical waveguide ports to coaxial interfaces by adding 2.4 mm waveguide to coax adapters (SWC-2434431505-282F-R1 or SWC-2434431505-282M-R1), are available under different model numbers.
