WR-19 Waveguide Rectangular Horn Antenna

23 dBi Gain, 40 to 60 GHz, U-Band
SKU:SAR-2309-19-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAR-2309-19-S2 is a U-band pyramidal horn antenna that operates from 40 to 60 GHz. The antenna offers 23 dBi nominal gain and a typical half power beamwidth of 10 degrees on the E-plane and 11 degrees on the H-plane. The antenna supports linear polarized waveforms. The input of this antenna is a WR-19 waveguide with UG-383/U-M flange.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 9 $650.00
10 - 24 $585.00
25 - 49 $526.50

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency40 GHz
Maximum Frequency60 GHz
Gain23 dBi
3 dB Beamwidth, E-Plane10°
3 dB Beamwidth, H-Plane11°
Return Loss23 dB
Antenna PortWR-19 Waveguide
