WR-15 Coaxial Rectangular Horn Antenna

23 dBi Gain, 50 to 75 GHz, 1 mm (F), Right Angle, V-Band
SKU:SAR-2309-151F-R2
Availability:Contact Us for Quote
SAR-2309-151F-R2 is a V-band pyramidal horn antenna with a right angle (90°) 1 mm (F) coax connector to cover the frequency range of 75 GHz to 110 GHz. The antenna offers 23 dBi nominal gain and a typical half power beamwidth of 10.5 degrees on the E-plane and 12 degrees on the H-plane. The antenna supports linear polarized waveforms. End launch (180°) 1 mm (F) connector configuration is available under model SAR-2309-151F-E2.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency50 GHz
Maximum Frequency75 GHz
Gain23 dBi
3 dB Beamwidth, E-Plane10.5°
3 dB Beamwidth, H-Plane12°
Return Loss15 dB
Antenna Port90° 1 mm Female
