J-Band Fixed Attenuator, High Precision

220 to 330 GHz, 20 dB, WR-03 Waveguide
SKU:STA-20-03-F1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
STA-20-03-F1 is a 20 dB fixed attenuator that is used in millimeterwave systems and operates from 220 to 330 GHz. The attenuator has a fixed attenuation value of 20 dB at center frequency, 275 GHz. While the attenuator is designed for full waveguide band applications, the attenuation value does show a minor slope within the band due to its distinct mechanical configuration. Various attenuation values are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency220 GHz
Maximum Frequency330 GHz
Attenuation20 dB @ 275 GHz
Return Loss16 dB
Power Handling100 mW
RF PortWR-03 Waveguide
Attenuator TypeFixed
