J-Band Fixed Attenuator, Limited Run

220 to 330 GHz, 10 dB, WR-03 Waveguide
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider STA-10-03-F1 as an alternative solution. Read more about Limited Run Products here.

STA-10-03-F2 is a 10 dB fixed attenuator that is used in millimeterwave systems and operates from 220 to 330 GHz. The attenuator has a fixed attenuation value of 10 dB at the center frequency, 275 GHz. While the attenuator is designed and fabricated for full waveguide band applications, the attenuation value of this model does show a minor slope within the band due to its distinct mechanical configuration. Other attenuation values are available under different model numbers as STA-XX-03-F2, where XX is the desired attenuation value.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency220 GHz
Maximum Frequency330 GHz
Attenuation10 dB @ 275 GHz
Return Loss16 dB
Power Handling0.3 W
RF PortWR-03 Waveguide
Attenuator TypeFixed
