X2 Active Frequency Multiplier with Uni-Guide™

22 to 44 GHz, +20 dBm Output Power, In-line WR-28 Waveguide, Ka-Band
SFA-223443220-28SF-E1 is an active X2 frequency multiplier. The multiplier has an input frequency of 11 to 22 GHz with a typical input power of +5 dBm and an output frequency of 22 to 44 GHz with a typical output power of +20 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The DC power requirement for the multiplier is +8 VDC/300 mA. The input port of this model is a female SMA connector and the output port is a WR-28 Uni-Guide™ waveguide with a UG-599/U flange. It is an in-line angle configuration. Other port configurations, such as right angle, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency22 GHz
Maximum Output Frequency44 GHz
Output Power+20 dBm
Minimum Input Frequency11 GHz
Maximum Input Frequency22 GHz
Input Power+5 dBm
DC Bias+8 VDC/300 mA
Output PortWR-28 Uni-Guide™ WG
Input PortSMA (F)
