X2 Active Frequency Multiplier

22 to 44 GHz, +16 dBm Output Power, SMA (F) Input, 2.92 mm (F) Output
SKU:SFA-223443216-KFSF-E1
Availability:1 Week ARO
SFA-223443216-KFSF-E1 is an active X2 frequency multiplier. The multiplier has an input frequency of 11 to 22 GHz with a typical input power of +5 dBm and an output frequency of 22 to 44 GHz with a typical output power of +16 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The DC power requirement for the multiplier is +8 VDC/300 mA. The input port is a female SMA connector and the output is a 2.92mm K female connector. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 2 $2,750.00
3 - 4 $2,612.50
5 - 9 $2,481.88

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency22 GHz
Maximum Output Frequency44 GHz
Output Power+16 dBm
Minimum Input Frequency11 GHz
Maximum Input Frequency22 GHz
Input Power+5 dBm
DC Bias+8 VDC/300 mA
Output PortK (F)
Input PortSMA (F)
