WR-34 Band Level Setting Attenuator, Limited Run

22 to 33 GHz, 0 to 30 dB, WR-34 Waveguide
SKU:STA-30-34-M3-2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider STA-30-34-M1 as an alternative solution. Read more about Limited Run Products here.

STA-30-34-M3-2 is a WR-34 level setting attenuator that covers the frequency range of 22 to 33 GHz. The attenuator has a micrometer dial which allows for repeatable settings. The level setting attenuator is an ideal piece of equipment in waveguide systems where broadband level setting is required. The attenuator exhibits 0.2 dB typical insertion loss and up to 30 dB nominal attenuation.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency22 GHz
Maximum Frequency33 GHz
Attenuation0 to 30 dB
Return Loss21 dB
Power Handling1 W
RF PortWR-34 Waveguide
Attenuator TypeLevel Setting
ConfigurationStandard
