Broadband Low Noise Amplifier

20 to 44 GHz, 30 dB Gain, 4.0 dB Noise Figure, 2.4 mm (F)
SKU:SBL-2034433040-2F2F-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SBL-2034433040-2F2F-S1 is a low noise amplifier with a typical small signal gain of 30 dB and a nominal noise figure of 4.0 dB across the frequency range of 20 to 44 GHz. The DC power requirement for the amplifier is +8 VDC/160 mA. The mechanical configuration offers an inline structure with 2.4 mm female connectors. Other port configurations, such as male 1.85 mm connectors for either the input or output port, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 4 $2,200.00
5 - 9 $1,980.00
10 - 24 $1,782.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency20 GHz
Maximum Frequency44 GHz
Gain30 dB
Noise Figure4.0 dB
P1dB+15 dBm
Input Return Loss10 dB
Output Return Loss7 dB
DC Bias+8 VDC/160 mA
RF Input/Output2.4 mm (F)
