X2 Active Frequency Multiplier

20 to 40 GHz, +4 dBm Output Power, SMA (F) Input, 2.92 mm (F) Output
SKU:SFA-203403205-KFSF-S1
Availability:1 Week ARO
SFA-203403205-KFSF-S1 is an active X2 frequency multiplier. The multiplier has an input frequency of 10 to 20 GHz with a typical input power of +5 dBm and an output frequency of 20 to 40 GHz with a typical output power of +4 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The DC power requirement for the multiplier is +8 VDC/180 mA. The input port is a female SMA connector and the output is a female K connector. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,950.00
5 - 9 $1,755.00
10 - 24 $1,579.50

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency20 GHz
Maximum Output Frequency40 GHz
Output Power+4 dBm
Minimum Input Frequency10 GHz
Maximum Input Frequency20 GHz
Input Power+5 dBm
DC Bias+8 VDC/180 mA
Output PortK (F)
Input PortSMA (F)
