X2 Active Frequency Multiplier

20 to 40 GHz, +16 dBm Output Power, SMA (F) Input, 2.92 mm (F) Output
SKU:SFA-203403216-KFSF-S1
Availability:1 to 2 Weeks ARO
SFA-203403216-KFSF-S1 is an active X2 frequency multiplier. The multiplier has an input frequency of 10 to 20 GHz with a typical input power of +5 dBm and an output frequency of 20 to 40 GHz with a typical output power of +16 dBm. The multiplier also has a typical harmonic suppression of -20 dBc. The DC power requirement for the multiplier is +8 VDC/300 mA. The input port is a female SMA connector and the output is a female K connector. Other port configurations are available under different model numbers.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 2$2,850.00
3 - 4$2,707.50
5 +$2,572.13

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Output Frequency20 GHz
Maximum Output Frequency40 GHz
Output Power+16 dBm
Minimum Input Frequency10 GHz
Maximum Input Frequency20 GHz
Input Power+5 dBm
DC Bias+8 VDC/300 mA
Output PortK (F)
Input PortSMA (F)
