WR-51 Coaxial Rectangular Horn Antenna

20 dBi Gain, 14.5 to 22 GHz, SMA (F), Right Angle, K-Band
SKU:SAR-2018-51SF-R3
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAR-2018-51SF-R3 is a K-band pyramidal horn antenna with a right angle (90°) SMA type coax connector to cover the frequency range of 14.5 GHz to 22 GHz. The antenna offers 20 dBi nominal gain and a typical half power beamwidth of 17 degrees on the E-plane and 19 degrees on the H-plane. The antenna supports linear polarized waveforms.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency14.5 GHz
Maximum Frequency22 GHz
Gain20 dBi
3 dB Beamwidth, E-Plane17°
3 dB Beamwidth, H-Plane19°
Return Loss18 dB
Antenna Port90° SMA Female
