K-Band Conical Horn Antenna

20 dBi Gain, 24 to 26.5 GHz, 0.328" Diameter Circular Waveguide
SKU:SAC-2012-328-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAC-2012-328-S2 is a K-band conical horn antenna that operates from 24 to 26.5 GHz. The antenna offers 20 dB nominal gain and a typical half powerbeam width of 16 degrees on the E-plane and 20 degrees on the H-plane. The horn also offers typical sidelobes of -20 dB on the E-plane and -28 dB on the H-plane. The conical horn can support linear and circular polarization. The input of this antenna is a 0.328" diameter circular waveguide with UG-595/U-M flange.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency24 GHz
Maximum Frequency26.5 GHz
Gain20 dBi
3 dB Beamwidth, E-Plane16°
3 dB Beamwidth, H-Plane20°
Return Loss23 dB
PolarizationLinear and Circular
Antenna Port0.328" Dia Circular WG
