U-Band Conical Horn Antenna, Wellprice

This is a Wellprice model that may not be offered in the future. Customers who anticipate long-term requirements should consider SAC-2012-165-S2 as an alternative solution. Read more about Wellprice Products here.

SAC-2012-165-S2-WP is a U-band conical horn antenna that operates from 50 to 60 GHz. The antenna offers 20 dB nominal gain and a typical half powerbeam width of 16 degrees on the E-plane and 20 degrees on the H-plane. The horn also offers typical sidelobes of -20 dB on the E-plane and -28 dB on the H-plane. The conical horn can support linear and circular polarization. The input of this antenna is a 0.165" diameter circular waveguide with UG-383/U-M flange.
