Broadband Low Noise Amplifier

2 to 22 GHz, 27 dB Gain, 3.5 dB Noise Figure, 2.92 mm (F)
SKU:SBL-0232232735-KFKF-E3
SBL-0232232735-KFKF-E3 is a broadband amplifier with a typical small signal gain of 27 dB, a nominal P1dB of +8 dBm, and a maximum noise figure of 3.5 dB across the frequency range of 2 to 22 GHz. The DC power requirement for the amplifier is +15 VDC/300 mA. The RF connectors are female K connectors. Other connector configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,950.00
5 - 9 $1,755.00
10 - 24 $1,579.50

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency2 GHz
Maximum Frequency22 GHz
Gain27 dB
Noise Figure3.5 dB
P1dB+8 dBm
Input Return Loss14 dB
Output Return Loss14 dB
DC Bias+15 VDC/300 mA
RF Input/Output2.92 mm (F)
