Broadband Amplifier

18 to 40 GHz, 40 dB Gain, +18 dBm P1dB, 6.0 dB Noise Figure, 2.92 mm (F)
SKU:SBB-1834034018-KFKF-E3
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SBB-1834034018-KFKF-E3 is a broadband amplifier with a typical small signal gain of 40 dB, a nominal P1dB of +18 dBm, and a typical noise figure of 6.0 dB across the frequency range of 18 to 40 GHz. The DC power requirement for the amplifier is +12 VDC/650 mA. The use of a heat sink is advised to assist in cooling the device. The RF connectors are female K connectors. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 2 $3,150.00
3 - 4 $2,992.50
5 - 9 $2,842.88

Bulk Availability

QuantityAvailability
1 - 5In Stock

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency40 GHz
Gain40 dB
P1dB+18 dBm
Psat+19 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+12 VDC/650 mA
RF Input/OutputK (F)
