K-Band Level Setting Attenuator

STA-30-42-M1 is a K-band level setting attenuator that covers the frequency range from 18 to 26.5 GHz. The attenuator features a precision micrometer dial with a knurled head locking screw, which allows for stable, repeatable settings that can be locked at any attenuation value. The level setting attenuator is an ideal piece of equipment in waveguide systems where broadband attenuation is required. The attenuator exhibits 0.2 dB typical insertion loss and up to 30 dB nominal attenuation value across the entire operating bandwidth. The other attenuator types, such as direct reading, programmable and fixed tuned attenuators are also available under different model numbers.
