8-Way Coaxial Power Splitter

18 to 26.5 GHz, SMA (F)
SKU:SCS-1832732216-SFSF-82
Availability:4 to 6 Weeks ARO
SCS-1832732216-SFSF-82 is a coaxial 8-way power splitter with a typical insertion loss of 2.2 dB at each output port and a typical isolation of 16 dB across the frequency range of 18 to 26.5 GHz. The power splitter has a nominal power handling of 30 W (CW) and a typical amplitude unbalance of ±0.6 dB. The return loss for all ports is 11 dB typical. The RF connectors of the power splitter are female SMA connectors.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 4 $1,200.00
5 - 9 $1,080.00
10 - 24 $972.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency26.5 GHz
Ways8
Insertion Loss2.2 dB
Port Isolation16 dB
Return Loss11 dB
Impedance50 Ohms
RF ConnectorsSMA (F)
