4-Way Coaxial Power Splitter

18 to 26.5 GHz, SMA (F)
SKU:SCS-1832731616-SFSF-42
Availability:4 to 6 Weeks ARO
SCS-1832731616-SFSF-42 is a coaxial 4-way power splitter with a typical insertion loss of 1.6 dB at each output port and a typical isolation of 16 dB across the frequency range of 18 to 26.5 GHz. The power splitter has a nominal power handling of 20 W (CW) and a typical amplitude unbalance of ±0.5 dB. The return loss for all ports is 12 dB typical. The RF connectors of the power splitter are female SMA connectors.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 9$550.00
10 - 24$495.00
25 - 49$445.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency26.5 GHz
Ways4
Insertion Loss1.6 dB
Port Isolation16 dB
Return Loss12 dB
Impedance50 Ohms
RF ConnectorsSMA (F)
