K-Band Orthomode Transducer

18 to 26.5 GHz, 40 dB Isolation, -35 dB Cross Polarization, 0.420" x 0.420" Square Waveguide Antenna Port
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAT-FK-42042-S1 is a full band, WR-42 orthomode transducer (OMT) that operates between 18 and 26.5 GHz. The OMT separates a circularly or elliptically polarized waveform into two linear, orthogonal waveforms or combines two linearly polarized waveforms into one circularly or elliptically polarized waveform. The OMT shows high port isolation and high cross-polarization cancellation while maintaining a low insertion loss. The OMT is configured with a 0.420" x 0.420" square waveguide for the antenna port and two WR-42 waveguides for the horizontal and vertical ports. All ports have UG-595/U flanges with 4-40 threaded holes.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency26.5 GHz
Insertion Loss, Antenna to V Port0.5 dB
Insertion Loss, Antenna to H Port0.5 dB
Isolation45 dB
Cross Polarization-35 dB
Antenna Port0.420" x 0.420" Square WG
Horizontal and Vertical PortsWR-42 WG
