WR-04 Fixed Attenuator, Limited Run

170 to 260 GHz, 3 dB, WR-04 Waveguide
SKU:STA-03-04-F2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider STA-03-04-F1 as an alternative solution. Read more about Limited Run Products here.

STA-03-04-F2 is a 3 dB fixed attenuator that is used in millimeterwave systems and operates from 170 to 260 GHz. The attenuator has a fixed attenuation value of 3 dB at the center frequency, 215 GHz. While the attenuator is designed and fabricated for full waveguide band applications, the attenuation value of this model does show a minor slope within the band due to its distinct mechanical configuration. Other attenuation values are available under different model numbers as STA-XX-04-F2, where XX is the desired attenuation value.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 9 $800.00
10 - 24 $720.00
25 - 49 $648.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency170 GHz
Maximum Frequency260 GHz
Attenuation3 dB @ 215 GHz
Return Loss16 dB
Power Handling0.3 W
RF PortWR-04 Waveguide
Attenuator TypeFixed
