WR-04 Band Fixed Attenuator, High Precision

170 to 260 GHz, 10 dB, WR-04 Waveguide
SKU:STA-10-04-F1
Availability:1 Week ARO
STA-10-04-F1 is a 10 dB fixed attenuator that is used in millimeterwave systems and operates from 170 to 260 GHz. The attenuator has a fixed attenuation value of 10 dB at center frequency, 215 GHz. While the attenuator is designed for full waveguide band applications, the attenuation value does show a minor slope within the band due to its distinct mechanical configuration. Various attenuation values are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency170 GHz
Maximum Frequency260 GHz
Attenuation10 dB @ 215 GHz
Return Loss16 dB
Power Handling100 mW
RF PortWR-04 Waveguide
Attenuator TypeFixed
