SMA Coaxial Bandpass Filter

17 to 17.34 GHz, 40 dB Rejection
SKU:SCF-18301360-SFSF-B3
Availability:6 to 8 Weeks ARO
SCF-18301360-SFSF-B3 is a coaxial bandpass filter with a passband frequency of 17 to 18 GHz. The typical insertion loss of the bandpass filter is 0.8 dB and the passband ripple is ±0.3 dB. The rejection frequencies are 15.5 GHz or less and 19.5 GHz or higher. The typical rejection is 60 dB and the typical passband return loss of the filter is 14 dB. The RF connectors of the the filter are SMA Female connectors. Other configurations are available under different model numbers.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 9$760.00
10 - 24$684.00
25 +$615.60

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Passband Frequency17 GHz
Maximum Passband Frequency18 GHz
Low Side Rejection60 dB
High Side Rejection60 dB
Return Loss14 dB
Insertion Loss0.8 dB
Impedance50 Ohms
RF PortsSMA (F)
