Ka-Band Scalar Feed Horn Antenna

17 dBi Gain, 26 to 33 GHz, 0.315" Diameter Circular Waveguide
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAF-2633331725-315-S1 is a Ka-band scalar feed horn antenna that operates from 26 to 33 GHz. The antenna offers a 17 dB nominal gain, 25 degree typical half power beamwidth, and -28.5 dB typical sidelobe level. The scalar feed horn is equipped with a 0.315" diameter circular waveguide that supports both linear and circular polarization. A rectangular waveguide port configuration that only supports linear polarization is available under a different model number.
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 4 $1,650.00
5 - 9 $1,485.00
10 - 24 $1,336.50

Bulk Availability


Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency26 GHz
Maximum Frequency33 GHz
Gain17 dBi
3 dB Beamwidth, E-plane25°
3 dB Beamwidth, H-plane25°
Return Loss20 dB
PolarizationLinear and Circular
Antenna Port0.315" Dia Circular WG
