G-Band Scalar Feed Horn Antenna

17 dBi Gain, 140 to 220 GHz, 0.067" Diameter Circular Waveguide
SKU:SAF-1442241725-067-S1
Availability:4 to 6 Weeks ARO
SAF-1442241725-067-S1 is a G-band scalar feed horn antenna that operates from 140 to 220 GHz. The antenna offers a 17 dBi nominal gain, 25 degree typical half power beamwidth, and -25 dB typical side lobe level. The scalar feed horn is equipped with a 0.067" diameter circular waveguide that supports both linear and circular polarization. A rectangular waveguide port configuration that only supports linear polarization is available under a different model number.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 2$2,950.00
3 - 4$2,802.50
5 - 9$2,662.38

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency140 GHz
Maximum Frequency220 GHz
Gain17 dBi
3 dB Beamwidth, E-plane25°
3 dB Beamwidth, H-plane25°
Return Loss20 dB
PolarizationLinear and Circular
Antenna Port0.067" Dia Circular WG
