F-Band Scalar Feed Horn Antenna

17 dBi Gain, 100 to 112 GHz, 0.082" Diameter Circular Waveguide
SKU:SAF-1041141725-082-S1
Availability:4 to 6 Weeks ARO
SAF-1041141725-082-S1 is an F-band scalar feed horn antenna that operates from 100 to 112 GHz. The antenna offers a 17 dB nominal gain, 25 degree typical half power beamwidth, and -28.5 dB typical sidelobe level. The scalar feed horn is equipped with a 0.082" diameter circular waveguide that supports both linear and circular polarization. A rectangular waveguide port configuration that only supports linear polarization is available under a different model number.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 4$2,150.00
5 - 9$1,935.00
10 - 24$1,741.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency100 GHz
Maximum Frequency112 GHz
Gain17 dBi
3 dB Beamwidth, E-plane25°
3 dB Beamwidth, H-plane25°
Return Loss20 dB
PolarizationLinear and Circular
Antenna Port0.082" Dia Circular WG
