Ku-Band Conical Horn Antenna

17 dBi Gain, 15 to 18 GHz, 0.660" Diameter Circular Waveguide
SKU:SAC-1626-660-C2
Availability:4 to 6 Weeks ARO
SAC-1626-660-C2 is an Ku-band conical horn antenna that operates from 15 to 18 GHz. The antenna offers 17.0 dB nominal gain and a typical half power beamwidth of 22 degrees on the E-plane and 26.5 degrees on the H-plane. The horn also offers typical sidelobes of -12 dB on the E-plane and -18 dB on the H-plane, respectively. The conical horn can support linear and circular polarization. The input of this antenna is a 0.66" diameter circular waveguide with UG419/U-M flange.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 4$1,100.00
5 - 9$990.00
10 +$891.00

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency15 GHz
Maximum Frequency18 GHz
Gain17 dBi
3 dB Beamwidth, E-Plane22°
3 dB Beamwidth, H-Plane26.5°
Return Loss20 dB
PolarizationLinear and Circular
Antenna Port0.66" Dia Circular WG
