K-Band Linear to Circular Polarizer

17.5 to 22 GHz, 1.1 Axial Ratio, 0.470" Diameter Circular Waveguide
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAS-203-47042-F1 is a K band, linear to circular polarizer that operates from 17.5 to 22 GHz. The polarizer offers a typical insertion loss of 0.5 dB, a typical axial ratio of 1.1, and a typical return loss of 17 dB. The polarizer is fixed and can be used for either right-handed or left-handed polarization based on the direction of the input signal. The polarizer input and output port is a 0.470” diameter waveguide with UG-595/U-M flange. The polarizer is often combined with Eravant’s rectangular to circular waveguide transition (SWT-42470-SA) and WR-42 conical horn antenna (SAC-2309-470-S2) for various system applications.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,650.00
5 - 9 $1,485.00
10 - 24 $1,336.50

Bulk Availability


Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency17.5 GHz
Maximum Frequency22 GHz
Insertion Loss0.5 dB
Axial Ratio1.1
Return Loss17 dB
Input/Output0.470" Diameter Circular Waveguide
