SMA Coaxial Bandpass Filter

SCF-16303260-SFSF-B3 is a coaxial bandpass filter with a passband frequency of 16.25 to 16.55 GHz. The typical insertion loss of the bandpass filter is 0.8 dB and the passband ripple is ±0.3 dB. The rejection frequencies are 14.85 GHz or less and 17.85 GHz or higher. The typical rejection is 60 dB and the typical passband return loss of the filter is 16 dB. The RF connectors of the the filter are SMA Female connectors. Other configurations are available under different model numbers.
