WR-112 Waveguide Square Horn Antenna

15 dBi Gain, 7 to 10 GHz, 112-Band
SKU:SAR-1532-1122-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-0400GAIN-AA.
A 2D pattern measurement test is offered under service number FTA-0400PATT-AA.

CLICK HERE to read more about our antenna measurement capabilities.

SAR-1532-1122-S2 is a square horn antenna that operates from 7 GHz to 10 GHz. The antenna offers 15 dBi nominal gain and a typical half power beamwidth of 22 degrees on the E-plane and 32 degrees on the H-plane. The antenna supports linear polarized waveforms. The input of this antenna is a 1.122" X 1.122" waveguide with UG-51/U-M flange.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency7 GHz
Maximum Frequency10 GHz
Gain15 dBi
3 dB Beamwidth, E-Plane22°
3 dB Beamwidth, H-Plane32°
Return Loss25 dB
Antenna Port1.122" x 1.122" Square WG
