WR-10 Coaxial Rectangular Horn Antenna

15 dBi Gain, 75 to 110 GHz, 1 mm (F), W-Band
SKU:SAR-1532-101F-E2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAR-1532-101F-E2 is a W-band pyramidal horn antenna with a end launch (180°) 1 mm (F) coax connector to cover the frequency range of 75 GHz to 110 GHz. The antenna offers 15 dBi nominal gain and a typical half power beamwidth of 32 degrees on the E-plane and 32 degrees on the H-plane. The antenna supports linear polarized waveforms. Right angle (90°) 1 mm (F) connector configuration is available under model SAR-1532-101F-R2.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency75 GHz
Maximum Frequency110 GHz
Gain15 dBi
3 dB Beamwidth, E-Plane32°
3 dB Beamwidth, H-Plane32°
Return Loss15 dB
Antenna Port1 mm Female
