W-Band Scalar Feed Horn Antenna

This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-WR10GAIN-AA.
A 2D pattern measurement test is offered under service number FTA-WR10PATT-AA.

CLICK HERE to read more about our antenna measurement capabilities.

SAF-7531141535-110-S1 is a W-band scalar feed horn antenna that operates from 75 to 110 GHz. The antenna offers a 15 dBi nominal gain, 35 degree typical half power beamwidth, and -25 dB typical side lobe level. The scalar feed horn is equipped with a 0.110" diameter circular waveguide that supports both linear and circular polarization. A rectangular waveguide port configuration that only supports linear polarization is available under a different model number.
