G-Band Fixed Attenuator, High Precision

140 to 220 GHz, 6 dB, WR-05 Waveguide
STA-06-05-F1 is a 6 dB fixed attenuator that is used in millimeterwave systems and operates from 140 to 220 GHz. The attenuator has a fixed attenuation value of 6 dB at center frequency, 180 GHz. While the attenuator is designed for full waveguide band applications, the attenuation value does show a minor slope within the band due to its distinct mechanical configuration. Various attenuation values are available under different model numbers.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency140 GHz
Maximum Frequency220 GHz
Attenuation6 dB @ 180 GHz
Return Loss16 dB
Power Handling100 mW
RF PortWR-05 Waveguide
Attenuator TypeFixed
