G-Band Negative Amplitude Detector

140 to 220 GHz, 200 mV/mW Sensitivity, WR-05 Waveguide
SKU:SFD-144224-05SF-N1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SFD-144224-05SF-N1 is a G Band amplitude detector that can be used for full or narrow band applications. The detector is zero biased and intended for small signal detection purposes. With a distinct circuitry design and careful diode selection, the detector exhibits high sensitivity and extremely flat output characteristics across the full waveguide operating bandwidth. The detector is designed to have a 10 MHz video bandwidth and a 1 MΩ video output impedance. The minimum detectable signal level is approximately -45 dBm.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 2 $2,650.00
3 - 4 $2,517.50
5 - 9 $2,391.63

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency140 GHz
Maximum Frequency220 GHz
Sensitivity200 mV/mW
Sensitivity Flatness±2.0 dB
RF Input Power-20 dBm
Video Bandwidth10 MHz
Output Voltage PolarityNegative
RF PortWR-05 Waveguide
DC PortSMA (F)
