WR-04 Faraday Isolator

140 to 220 GHz, 20 dB Isolation, 4.0 dB Insertion Loss, WR-05 Waveguide
Availability:4 to 6 Weeks ARO
STF-05-S1 is a full band Faraday isolator that operates from 140 to 220 GHz. The Faraday isolator is constructed with a longitudinal, magnetized ferrite rod that causes a Faraday rotation of the incoming RF signal. The Faraday isolator offers 20 dB typical isolation and 4 dB nominal insertion loss with good flatness. The return loss of the isolator is 14 dB. The input and output ports are WR-05 waveguides with UG-387/U-M flanges.
To view pricing or check order status

Bulk Pricing

1 - 2$2,650.00
3 - 4$2,517.50
5 +$2,391.63

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency140 GHz
Maximum Frequency220 GHz
Insertion Loss4 dB
Isolation20 dB
Return Loss14 dB
Power Handling0.2 W
RF PortWR-05 Waveguide
