G-Band Fixed Attenuator, Limited Run

140 to 220 GHz, 10 dB, WR-05 Waveguide
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider STA-10-05-F1 as an alternative solution. Read more about Limited Run Products here.

STA-10-05-F2 is a 10 dB fixed attenuator that is used in millimeterwave systems and operates from 140 to 220 GHz. The attenuator has a fixed attenuation value of 10 dB at the center frequency, 180 GHz. While the attenuator is designed and fabricated for full waveguide band applications, the attenuation value of this model does show a minor slope within the band due to its distinct mechanical configuration. Various attenuation values are available under different model numbers.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency140 GHz
Maximum Frequency220 GHz
Attenuation10 dB @ 180 GHz
Return Loss16 dB
Power Handling0.3 W
RF PortWR-05 Waveguide
Attenuator TypeFixed
