G-Band Spot-Focusing Lens Antenna

SAQ-184010-05-S1 is a WR-05 spot-focusing lens antenna that delivers a typical 10 dB spot size of 0.076" at the focal length of 1.0", and a typical return loss of 14 dB across the full WR-05 waveguide operating bandwidth. The spot-focusing lens antenna is equipped with a WR-05 waveguide and UG-387/U-M flange as its antenna port. It supports linear polarized waveforms. These antennas are recommended to be purchased as a set of two. For the intended application, it is recommended that customers purchase spot-focusing antennas (SAQ Series) in a pair of two (Qty. 2).
