WR-42 Waveguide Rectangular Horn Antenna

14 dBi Gain, 18 to 26.5 GHz, K-Band
SKU:SAR-1430-42-S2-D
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-0400GAIN-AA.
A 2D pattern measurement test is offered under service number FTA-0400PATT-AA.

CLICK HERE to read more about our antenna measurement capabilities.

SAR-1430-42-S2-D is a K-band pyramidal horn antenna that operates from 18 to 26.5 GHz. The antenna offers 14 dBi nominal gain and a typical half power beamwidth of 33 degrees on the E-plane and 33 degrees on the H-plane. The antenna supports linear polarized waveforms. The input of this antenna is a WR-42 waveguide with UG-595/U flange.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency26.5 GHz
Gain14 dBi
3 dB Beamwidth, E-Plane33°
3 dB Beamwidth, H-Plane33°
Return Loss23 dB
Antenna PortWR-42 Waveguide
