SMA Coaxial Bandpass Filter

14.8 to 15.8 GHz, 70 dB Rejection
SKU:SCF-15301370-SFSF-B3
Availability:6 to 8 Weeks ARO
SCF-15301370-SFSF-B3 is a coaxial bandpass filter with a passband frequency of 14.8 to 15.8 GHz. The typical insertion loss of the bandpass filter is 1 dB and the passband ripple is ±0.5 dB. The rejection frequencies are 12.4 GHz or less and 17.5 GHz or higher. The typical rejection is 70 dB and the typical passband return loss of the filter is 14 dB. The RF connectors of the the filter are SMA Female connectors. Other configurations are available under different model numbers.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 9$760.00
10 - 24$684.00
25 - 49$615.60

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Passband Frequency14.8 GHz
Maximum Passband Frequency15.8 GHz
Low Side Rejection70 dB
High Side Rejection70 dB
Return Loss14 dB
Insertion Loss1 dB
Impedance50 Ohms
RF PortsSMA (F)
