WR-08 Waveguide Bandpass Filter

119.5 to 120.5 GHz Passband, 40 dB Rejection from DC to 117 GHz and 123 to 130 GHz, F-Band
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWF-12401340-08-B1 is an F band waveguide bandpass filter with a passband frequency of 119.5 to 120.5 GHz and rejection frequencies from DC to 117 GHz and 123 to 130 GHz. The nominal insertion loss of the bandpass filter is 2.5 dB and the typical rejection is 40 dB. Since both low end and high end cut off frequencies can be selected by modifying the design, custom designs are available under different model numbers.
Login to view pricing

Technical Details

Minimum Passband Frequency119.5 GHz
Maximum Passband Frequency120.5 GHz
Minimum Rejection Frequency, Low SideDC
Maximum Rejection Frequency, Low Side117 GHz
Minimum Rejection Frequency, High Side123 GHz
Maximum Rejection Frequency, High Side130 GHz
Rejection40 dB
Waveguide PortWR-08 Waveguide
