D-Band Faraday Isolator, Wellprice

110 to 170 GHz, 30 dB Isolation, 4.0 dB Insertion Loss, WR-06 Waveguide, 90° Twist
SKU:STF-1141744030-06-91-WP
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This is a Wellprice model that may not be offered in the future. Customers who anticipate long-term requirements should consider STF-06-91-M2 as an alternative solution. Read more about Wellprice Products here.

STF-1141744030-06-91-WP is a full band Faraday isolator that operates from 110 to 170 GHz. The Faraday isolator is constructed with a longitudinal, magnetized ferrite rod that causes a Faraday rotation of the incoming RF signal. The Faraday isolator offers 30 dB typical isolation and 4.0 dB nominal insertion loss with good flatness. The return loss of the isolator is 15 dB. The input and output ports are WR-06 waveguides with UG-387/U-M flanges and feature a 90? twist.
ECCN: EAR99
Login to view pricing

Technical Details

Minimum Frequency110 GHz
Maximum Frequency170 GHz
Insertion Loss4 dB
Isolation30 dB
Return Loss15 dB
Power Handling0.8 W
RF PortWR-06 Waveguide
ConfigurationStandard
