D-Band Phase Shifter, Limited Run

110 to 170 GHz, 0 to 180 ° Range, WR-06 Waveguide
SKU:STP-18-06-M1
This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider STP-18-06-M1-C-1.2 as an alternative solution. Read more about Limited Run Products here.

STP-18-06-M1 is a D-Band micrometer driven phase shifter that covers the frequency range of 110 to 170 GHz. The phase shifter features a precision micrometer dial with a knurled head locking screw, which allows for stable, repeatable settings that can be locked at any phase shift value. The phase shifter is an ideal piece of equipment in waveguide systems where broadband phase shifting is required. The phase shifter exhibits a 2.0 dB typical insertion loss and an adjustable phase range of up to 180 degrees.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency110 GHz
Maximum Frequency170 GHz
Insertion Loss2.0 dB
Phase Shifting Range0 to 180°
Power Handling400 mW (CW)
Input/OutputWR-06 Waveguide
