WR-08 Waveguide Highpass Filter

110 GHz and Higher Passband, 40 dB Rejection from DC to 105 GHz, F-Band
SKU:SWF-11411440-08-H1
SWF-11411440-08-H1 is an F band waveguide highpass filter with a passband frequency of 110 GHz and higher and a rejection frequency from DC to 105 GHz. The filter provides a nominal insertion loss of 2.5 dB across its passband with a low ripple and a typical rejection of 40 dB. Since the low end cutoff frequency can be changed by modifying the design, custom designs can be offered under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,550.00
5 - 9 $1,395.00
10 - 24 $1,255.50

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Passband Frequency110 GHz
Passband Insertion Loss2.5 dB
Minimum Rejection FrequencyDC
Maximum Rejection Frequency105 GHz
Rejection40 dB
Waveguide PortWR-08 Waveguide
