V-Band Conical Horn Antenna

10 dBi Gain, 58 to 68 GHz, 0.141" Diameter Circular Waveguide
SKU:SAC-1055-141-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAC-1055-141-S2 is a V-band conical horn antenna that operates from 58 to 68 GHz. The antenna offers 10.4 dBi nominal gain and a typical half power beamwidth of 49 degrees on the E-Plane and 60 degrees on the H-Plane. The horn also offers typical side lobes of -30 dB on the E-Plane and -15 dB on the H-Plane. The conical horn antenna can support linear and circular polarization. The input of this antenna is a 0.141" diameter circular waveguide with UG-385/U flange.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 24 $465.00
25 - 49 $418.50
50 - 99 $376.65

Bulk Availability

QuantityAvailability
1 - 5In Stock

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency58 GHz
Maximum Frequency68 GHz
Gain10 dBi
3 dB Beamwidth, E-Plane49°
3 dB Beamwidth, H-Plane60°
Return Loss23 dB
PolarizationLinear and Circular
Antenna Port0.141" Dia Circular WG
