Coaxial Fixed Attenuator

10 dB Attenuation, 2.4 mm (M) to (F), DC to 50 GHz, 2 Watt
SKU:SCA-10-2M2F-S9
Availability:3 Days ARO
SCA-10-2M2F-S9 is a 10 dB coaxial attenuator that is used in millimeterwave systems and operates from DC to 50 GHz. The attenuator has a typical attenuation value of 10 dB across the frequency range. While the attenuator is designed and fabricated for full 2.4 mm coaxial band applications, the attenuation value of this model will have a wide range due to its broadband coverage. Various attenuation values are available under different model numbers.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 24$335.00
25 - 49$301.50
50 +$271.35

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum FrequencyDC
Maximum Frequency50 GHz
Attenuation10 dB
Return Loss17 dB
Power Handling2 W
Connector 12.4 mm Male
Connector 22.4 mm Female
