4-Way Coaxial Power Splitter

1 to 40 GHz, 2.92 mm (F)
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SCS-0134035014-KFKF-42 is a coaxial 4-way power splitter with a typical insertion loss of 5 dB at each output port and a typical isolation of 14 dB across the frequency range of 1 to 40 GHz. The power splitter has a nominal power handling of 20 W (CW) and a typical amplitude unbalance of ±0.8 dB. The return loss for all ports is 9 dB typical. The RF connectors of the power splitter are female 2.92 mm (K) connectors.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 2 $2,900.00
3 - 4 $2,755.00
5 - 9 $2,617.25

Bulk Availability


Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency1 GHz
Maximum Frequency40 GHz
Insertion Loss5.0 dB
Port Isolation14 dB
Return Loss9 dB
Impedance50 Ohms
RF ConnectorsK (F)
