4-Way Coaxial Power Splitter

1 to 18 GHz, SMA (F)
SKU:SCS-0131833015-SFSF-42
Availability:4 to 6 Weeks ARO
SCS-0131833015-SFSF-42 is a coaxial 4-way power splitter with a typical insertion loss of 3.0 dB at each output port and a typical isolation of 15 dB across the frequency range of 1 to 18 GHz. The power splitter has a nominal power handling of 30 W (CW) and a typical amplitude unbalance of ±0.6 dB. The return loss for all ports is 11 dB typical. The RF connectors of the power splitter are female SMA connectors.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 24$475.00
25 - 49$427.50
50 +$384.75

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency1 GHz
Maximum Frequency18 GHz
Ways4
Insertion Loss3.0 dB
Port Isolation15 dB
Return Loss11 dB
Impedance50 Ohms
RF ConnectorsSMA (F)
